SPW150
GATOR
Availability: | |
---|---|
Quantity: | |
High efficiency cardboard box and paper core shredder
High-performance shredders from Gator work according different principles. The high-speed three-shaft shredders with counter-comb for shredding gripper edges, large-format punching scraps and punching grids made of solid and corrugated board work according to the tearing principle. Our slow-running shredders for large-format paper and corrugated board scraps work according to the cutting-tearing principle, in which the toothed shafts rotate in opposite directions and at different speed |
Shredding video
Application:
Specially used for shredding waste cardboard, paper, box and paper core etc
Advantages:
Impressive paper core shredding unit weighs more than 2.8 tons, featuring sturdy construction and user friendly operation. The Paper Core Shredder has a frequency regulated, 18.5kW motor that drives the cutting mechanism. The cutters are produced from long-lasting, top quality, specially handed steel. A smart feeder controller regulates the feed so that shredding is guaranteed under any circumstance. The destructive power of the core shredder is particularly impressive. It shreds up to 100 cores per hour and is easy to operate. The cores, which can be up to 120 mm diameter plus wall thickness up to 30mm, are simply pushed into the intake and automatic feed them into the cutting device. The Core Shredder Unit can be set up to operate in less than a minute. It can be operated continuously, but it doesn’t need to be. Simply flip the switch, start the motor, and feed the cores. The shredded pieces can be easily recycled afterwards. |
Technical Date:
Model | SPW150 |
Maximum cardboard feeding width | 1500mm |
Maximum paper core shredding thickness | 30mm |
Maximum Cardboard shredding thickness | 80mm |
Power | 15KW |
Shredding size | random |
Shredding capacity | 800-1500 kg per hour |
Machine size | 2130(L)*1630(W)*1849(H)mm |
Machine weight | 2800 kgs |
High efficiency cardboard box and paper core shredder
High-performance shredders from Gator work according different principles. The high-speed three-shaft shredders with counter-comb for shredding gripper edges, large-format punching scraps and punching grids made of solid and corrugated board work according to the tearing principle. Our slow-running shredders for large-format paper and corrugated board scraps work according to the cutting-tearing principle, in which the toothed shafts rotate in opposite directions and at different speed |
Shredding video
Application:
Specially used for shredding waste cardboard, paper, box and paper core etc
Advantages:
Impressive paper core shredding unit weighs more than 2.8 tons, featuring sturdy construction and user friendly operation. The Paper Core Shredder has a frequency regulated, 18.5kW motor that drives the cutting mechanism. The cutters are produced from long-lasting, top quality, specially handed steel. A smart feeder controller regulates the feed so that shredding is guaranteed under any circumstance. The destructive power of the core shredder is particularly impressive. It shreds up to 100 cores per hour and is easy to operate. The cores, which can be up to 120 mm diameter plus wall thickness up to 30mm, are simply pushed into the intake and automatic feed them into the cutting device. The Core Shredder Unit can be set up to operate in less than a minute. It can be operated continuously, but it doesn’t need to be. Simply flip the switch, start the motor, and feed the cores. The shredded pieces can be easily recycled afterwards. |
Technical Date:
Model | SPW150 |
Maximum cardboard feeding width | 1500mm |
Maximum paper core shredding thickness | 30mm |
Maximum Cardboard shredding thickness | 80mm |
Power | 15KW |
Shredding size | random |
Shredding capacity | 800-1500 kg per hour |
Machine size | 2130(L)*1630(W)*1849(H)mm |
Machine weight | 2800 kgs |
